Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors

Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors

    • Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors
    • Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors
  • Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors

    Product Details:

    Place of Origin: China
    Brand Name: SHINE OR OEM
    Certification: CE, RoHS, SGS, LVD
    Model Number: SN-SC160W

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: negiotation
    Packaging Details: 10 pcs per carton and then on pallet.
    Delivery Time: 5-8 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 10000 pcs per month
    Contact Now
    Detailed Product Description
    Front Material: High Efficiency SunPower Cells Dimension Open: 1720*530*5MM
    Weight: 3.6KGS Color: White Or Black
    Junction Box: IP67 With Diodes Connectors: 1.5m With MC4 Connectors
    Voltage: 27.8V Vmp Maximum Power Current (Imp): 5.7A
    High Light:

    curved solar panels

    ,

    folding solar panels

    High Efficiency Portable18V 60W Foldable Solar Panel Use Camping





    Glass

    > Antireflective glass
    > Translucency of normal luminance is increased by 2%
    > Module efficiency is increased by 2%
    > Self-cleaning function
    > Service life is as long as 25 years (30 years optional)





    Junction box

    > Conventional standalone edition and engineering custom edition
    > Quality diode ensures module running safety
    > IP67 protection level
    > Heat dissipation
    > Long service life



    That multifunctional portable solar charger, High efficiency, we have 2x40w and 3x40W two items, provide free power for charging 12V batteries, for example in vehicles and boats, motorhome , caravan, camping, narrow boat, yacht etc, or any other systems with a 12V battery or battery bank



    Cell brand                                sunpower and pet
    Power tolerance ±5%
    Peak power(WP) 160W
    Voltage at Pmax(Vmp) 27.8V
    Current at Pmax(lmp) 5.7A
    Open circuit voltaage(Voc) 33.4V
    Short circuit current(lsc) 6.27A
    Operating Temperature -25℃ +65℃
    Relative Humidity 0~100%
    Dimension Open 1720*530*5MM
    Dimension when folded 295*530*50MM
    Net Weight(kg) 3.6kg



    Other model and wattage:



    MODEL
    PM/w
    VOC/v
    ISC/A
    VMP/V
    IMP/A
    Cell/Array
    N/W(kg)
    Expand Size(mm)
    Folded Size(mm)
    SN-SC40W
    40
    23.76
    2.2
    19.8



    2.02
    (2*6)*3
    1.1
    840*295*5
    280*295*40
    SN-SC60W
    60
    23.76
    3.3
    19.8
    3.03
    (2*6)*3
    1.3
    840*400*5
    280*400*25
    SN-SC80W
    80
    24.80
    4.35
    20.2
    3.96
    (2*6)*4
    1.6
    1160*420*5
    290*420*30
    SN-SC110W
    110
    21.6
    6.52
    18
    6.1
    (2*4)*4
    2.2
    1160*530*5
    290*530*30
    SN-SC130W
    130
    27.84
    5.99
    23.2
    5.6
    (2*4)*5
    2.6
    1480*530*5
    290*530*40
    SN-SC160W
    160
    33.4
    6.27
    27.8
    5.7
    (2*4)*6
    3.6
    1720*530*5
    295*530*50



    Pictures



    Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors

    Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors

    Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors



    Our Services

    Pack and Service:



    1.usually packed in the cartons and pallets.



    2. Individual package is acceptable.



    Deliveried by air, sea,express are acceptablelly packed in the cartons and pallets.


    Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors
    Portable 18V 60W Foldable Solar Panel Antireflective Glass With MC4 Connectors
    FAQ


    FAQ:



    1.Question:

    Would this keep fully charged a 100Ah 12v battery used to power an led cricket scoreboard with 22 digits whilst in use?

    Answer:

    Good afternoon Jonwillie,
    teorically yes, it could keep 100Ah battery fully charged.
    But you must consider the sun and the consumption of your scoreboard.
    In a sunny day, solar panel will supply 5 Ah by hour. It means at best you will load 30 Ah - 6 hours x 5 Ah - in your battery; it is about 36% of its charge.
    If your scoreboard consume usually no more than 1/3 of battery, in a sunny day you will be able to keep battery fully charged.



    2.Question:

    how do you work out what amp controller you need for motorhome

    Answer:

    The correct controller was supplied with the panel, whole set up appears to work as it should, will also keep cab battery charged



    3.Question:

    Does it require additional brackets down the length of the panel. I only have 540mm width available.

    Answer:

    No additional brackets are required.



    4.Question:

    Would this keep a 12volt Campervan fridge running?

    Answer:



    I have a Waeco 12v fridge in my van and it runs it OK even sitting for 5 days without starting up the engine
